120
25kg
Paper Bags
1 Tonne
Bulk Bags
120 Mesh
Precision waterjet abrasive.
Ideal for thinner, softer and more brittle materials.
Good cutting speeds with a superior edge.
Consistent particle sizing that reduces downtime and maximises output.
Product
Application
Product
performance
120
Focusing Tube | Orifice |
|---|---|
0.02in (0.51mm) – 0.03in (0.76mm) | 0.007in (0.18mm) – 0.01in (0.25mm) |
| Focusing Tube | Orifice |
|---|---|
| 0.02in (0.51mm) – 0.03in (0.76mm) | 0.007in (0.18mm) – 0.01in (0.25mm) |
Technical
Features
Typical Chemical Analysis
Element | Presenting As | Conc.% |
|---|---|---|
Silica* | SiO2 | 35% |
Iron | Fe2O3 | 33% |
Alumina | Al2O3 | 19% |
Magnesium | MgO | 6% |
Calcium | CaO | 3% |
Managanese | MnO | 1% |
Titanium | TiO2 | 3% |
Chlorides^ | Cl- | 10-20pmm |
*Silica that is bound within the lattice of the garnet crystal and not free crystalline silica
^Chloride’s limit of 25pmm
Typical Physical Characteristics
Property | Value |
|---|---|
Specific Gravity | 4.2 |
Bulk Density | 2.2 T/m3 |
Hardness | 7 – 8 mohs |
Melting Point | 1,250°C / 2,250°F |
Conductivity | 10 – 15 mS/m |
Particle Shape | Sub Angular |
Fracture | Sub Conchoidal |
Moisture Absorption | Nil |
Magnetic Susceptibility | 600 gauss |
Radioactive | Non-Radioactive |
Typical Mineral Composition
Mineral | Presenting As | Conc. % |
|---|---|---|
Garnet (Almadine) | Fe3Al2(SiO4)3 | ≥ 96% |
Ilmenite | FeTiO3 | < 4% |
Zircon | ZrSiO4 | < 0.1% |
Crystalline Silica (free) | SiO22 | < 0.5% |
Other | < 1% |
Helping you achieve reliable results with every particle
